Rma

Overview

Basic Info.

Model NO.	ep200
Feature	Oil-Resistant, Heat-Resistant, Cold-Resistant, Wear-Resistant
Tensile Strength	Strong
Structure (for Chain)	Plain
Export Markets	Global
Color	Black
Usage	Transmission Chain, Transportation Chain, Dedica
Cover Rubber Grade	Rma1, Rma2, DIN-W, DIN-X, DIN-Y, DIN-K
Transport Package	Poly Bag
Specification	DIN22102/RMA
Trademark	kilomega
Origin	Ningbo, China
HS Code	40101200
Production Capacity	5000meters / Day

Packaging & Delivery

Package Size 100.00cm * 120.00cm * 100.00cm Package Gross Weight 100.000kg

Product Description

Product Description

CHEVRON CONVEYOR BELT
Polyester core conveyer belt is a multi-layer polyester canvas bonded together by a certain way, from top to bottom coverage of high strength, good wear-resistant flexible rubber, no special corrosion for the transmission of small and medium-sized block, powder, granular and other materials.
1.Standards:
GB/T7984-2001, DIN22102, BS490, AS1332, RMA, JISK6322, SABS1173 etc
2.Features:
Good flexibility, groove formation property and cost-effective. It is mainly used to transport powder,small and medium granular or less wearing materials at common temperature.
3.Application:Applicable to long-distance, high capacity, high-speed delivery of materials under the conditions.
Used in mining, quarries, chemical plants, architectural industry and etc.

Detailed Photos

Product Parameters

No	Item	Data
1	Cover Rubber grade	8MPA,10MPA,12MPA,15MPA 18MPA,20MPA,24MPA,26MPA
2	Belt width (mm)	400,500,600.650,700,900,800,1000,1200 1400,1500,1600,1800,2000,2200,2500
3	Tensile strength	EP200/2,EP315/2,EP315/3,EP400/3,EP500/3,EP600/3,EP400/4,EP500/4,EP630/4,EP800/4,EP1000/4,EP500/5,EP600/5,EP750/5, EP1000/5,EP1250/5 EP600/6,EP1200/6
4	Top+Bottom thickness	3+1.5, 4+2, 4+1.5, 4+3, 5+1.5, 6+2, 7+2, 8+2
5	Belt thickness	4mm-25mm
6	Belt length	50m, 100m, 200m, 250m, 300m
7	Belt edge type	moulded(rubbered) edge or cut edge

Fabric specs	Ply thickness (mm/p)	Strength series (N/mm)					Cover Thickness (mm)		Width	Length
		2ply	3ply	4ply	5ply	6ply	Top	Bottom	mm	m
EP80	0.60	160	240	320	400	480	2.0--8	0--4.5	400-2500	≤300
EP100	0.75	200	300	400	500	600
EP150	1.00	300	450	600	750	900
EP200	1.10	400	600	800	1000	1200			500 -- 2500
EP250	1.25	500	750	1000	1250	1500
EP300	1.35	600	900	1200	1500	1800
EP350	1.45		1050	1400	1750	2100			800 -- 2500
EP400	1.55			1600	2000	2400			1000 -- 2500
EP500	1.70			2000	2500	3000

Production Process

1. Rubber mix process 2. Calender process 3. Forming process 4. Vulcanizing process 5. Finish products

Quality Inspection

We have special QC department to inpect all the conveyor belt before shipment.
1. Surface Inspection
1.1 Width measurement
1.2 Length measurement
1.3 Thickness measurement
1.4 Surface inspection

2. Lab Inspection
2.1 Adhesion strength test
2.2 Tensile strength test
2.3 Abrasion test
2.4 Elongation test
2.5 Especial test according to customer's requirements

Packaging & Shipping

Successful Project

FAQ

Q1. Are you a manufactuer?Yes, we produce Rubber conveyor belts and conveyor rollers over 20 years. Q2. What is the lead time?10 days for bulk order production.30 days for container order production. Q3. How to pay?1. T/T or L/C through bank account
Q4. How about package?1. Inner is packed on round rubber core with 30cm diameter and 12cmx12cm square hole2. Outer is packed with one ply water-proof PP fabric3. With steel pallet on the bottom
